3.2V LiFePO4rechargeable li ion battery cell for Bluetooth Smart Card Reader
Features:
1. the single cell IFR10440/AA 240mAh ,the highest capacity for same size
2. There are IFR10400/AAA 200mAh/250mA for your section
3. The application for Digital Products/power tool , blue-tooth smart cards and more
4. Excellent abuse tolerance and environmentally friendly
5. Deep circle ,2000times circle life base on DOD 100%
Application:
Solar street light Solar Lawn and Led lighting
Small Robot and smart device
Tracking device , GPS equipment
intelligent vacuum cleaner
portable speaker products
Medical instrument breathing machine
desktop POS machines
portable equipment
Electrical bike , tour bus e-boat
Battery Specification List for 3.2V LiFePO4rechargeable li ion battery cell for Bluetooth Smart Card Reader
| No. | Items | Specifications | Remark |
| 1 | Nominal Capacity | 240mAh | 0.2C Standard discharge |
| 2 | Minimum Capacity | 220mAh |
| 3 | Nominal Voltage | 3.2V | Mean Operation Voltage |
| 4 | Delivery voltage | 3.28~3.32V | Within 10 days from Factory |
| 5 | Charge Voltage | 3.65V±0.03V | By standard charge method |
| 6 | Standard charging method | 0.2C constant current,3.65V constant voltage charge to 3.65V,continue charging till current decline to ≤0.01C | |
| 7 | Charge current | 0.2C | 480mA | Standard charge, charge time about 7h(Ref) |
| 1.0C | 240mA | Rapid Charge, charge time about: ::1.5h(Ref) |
| 8 | Standard discharging method | 0.2C constant current discharge to 2.5V, | |
| 9 | Cell Internal Impedance | ≤80mΩ | Internal resistance measured at AC 1KHZ after 50% charge |
| 10 | Maximum charge current | 1C | 240mA | For continuous charging mod |
| 11 | Maximum discharge current | 3C | 720mA | For continuous discharge mod(Discharge capacity for more than 80% of the nominal capacity) |
| 12 | Operation Temperature and relative humidity Range | Charge | 0~45℃ 60±25%R.H. | Charge at a very low temperature such as blew 0℃,will be get a lower capacity and reduce cycle life of the battery |
| Discharge | -20~60℃ 60±25%R.H. |
| 13 | Storage temperature for a long time | -20~25℃ 60±25%R.H. | Do not storage exceed half year. Must charge once when storage for half year. must charge the battery which with protect circuit when storage for three months. |
Similar Pictures for 3.2V LiFePO4rechargeable li ion battery cell for Bluetooth Smart Card Reader
Our serve:
We provide 24 months warranty,will change new products for you if quality problems.L Your inquiry related to our products or prices will be replied in 24 hours
We will track the shipping status time by time so that buyer can receive our goods in time and safely.
We could design all of the battery packs according to your requirements and provide OEM service.
We sincerely welcome you to visit and cooperate with us for business future.
Production Detail
After we assembled the cell with customer's require , we aging the battery pack one by one before shrink with pvc .
Production List For Lifepo4 Battery
